特点：
●体积小（8.5x8.5x3mm）
●声压高（3V时≥85dB）
●消耗电流（≤100mA，3.6V2.7kHZ）
●安装简便（编带贴片焊接）
电性能参数
Model No | BCE-MX8530A | |
Rated Voltage | 3.6V | 5V |
Min Sound Pressure Level | 85dB | 85dB |
Operating Voltage | 2~4V | 4~7V |
Max Current Consumption | <100mA | <80mA |
Resonant Frequency | 2.7KHz | 2.7KHz |
Coil lmpedance | 16±3Ω | 31±4Ω |
Housing Material | LCP | |
Operating Temperature | -30℃~+80℃ | |
Storage Temperature | -40℃~+85℃ | |
Weight | 0.4g | |
