特点：
●体积小（14x11x3.2mm）
●声压高（5V时≥90dB）
●消耗电流（≤80mA，5V2.73kHZ）
●安装简便（编带贴片焊接）
电性能参数
Model No | BCE-MX1411 |
Rated Voltage | 5V |
Min Sound Pressure Level | 90dB |
Operating Voltage | 3~7V |
Max Current Consumption | <80mA |
Resonant Frequency | 2.73KHz |
Coil lmpedance | 40±6Ω |
Housing Material | LCP |
Operating Temperature | -30℃~+80℃ |
Storage Temperature | -40℃~+85℃ |
Weight | 0.8g |
