特点:
●体积小(34.8x8.7mm)
●声压高(15V时≥90dB)
●消耗电流小(≤4mA,15V1.4kHZ)
●安装简便(卧式插入焊接)
电性能参数
Model No | BCE-31214 |
Min Sound Pressure Level | 90dB at 1.4KHZ at15Vp-p at 10cm |
Operating Voltage | 3~25V |
Max Current Consumption | <4mA |
Resonant Frequency | 1.4±0.5KHz |
Capacitance at 120HZ | 45±30%nF |
Housing Material | PPO |
Operating Temperature | -20℃~+70℃ |
Storage Temperature | -30℃~+80℃ |
Weight | 4.3g |
